Ultrasonic Plastic Welder CSH-2018
Specifications
Ultrasonic welding machine is primally used for point-by-point riveting, welding.
1.IC circuit controlling
2.Automatic over load protection
3.Self mold manufacturing workshop
4.Replacing traditional
Products Features:
1.Automatic frequency tracking system controlled by IC circuit
2.Original energy converter made in U.S.A,which is powerful and reliable
3.In case of error operation occurs,automatic over load protection will take effect
4.Equipped with import tube,to ensure ultrasonic output power as required
5.Four points based adjustable balance structure,which is easy and convenient for mold adjusting
6.With self mold manufacturing workshop,capable of USA 7075,6061 alloy aluminum mold model.
7.High tech electronic components for replacement of conventional electric crystal drive circuit,
which helps to increase response to 10 times faster than convenable type ,stable and less faults
Specifications:
|
Model
|
Frequency
|
Ultrasonic
power
|
Preforming
timer
|
Jointing
timer
|
Pressure
time
|
welding
area
|
dimension
|
Input
Power
|
Net
weight
|
|
CSH-2015
|
20KHZ
|
1000W
|
0.1~3S
|
0.01~3S
|
0.1~3S
|
100mm
|
L425*W630*H920
|
220V
|
95kg
|
|
CSH-2018
|
20KHZ
|
1500W
|
0.1~3S
|
0.01~3S
|
0.1~3S
|
150mm
|
L425*W630*H920
|
220V
|
95kg
|
|
CSH-1520
|
15KHZ
|
1800W
|
0.1~3S
|
0.01~3S
|
0.1~3S
|
160mm
|
L425*W630*H920
|
220V
|
110kg
|
|
CSH-1526
|
15KHZ
|
2600W
|
0.1~3S
|
0.01~3S
|
0.1~3S
|
200mm
|
L425*W630*H920
|
220V
|
115kg
|
|
CSH-1532
|
15KHZ
|
3200W
|
0.1~3S
|
0.01~3S
|
0.1~3S
|
240mm
|
L425*W630*H750
|
220V
|
300kg
|
|
CSH-1542
|
15KHZ
|
4200W
|
0.1~3S
|
0.01~3S
|
0.1~3S
|
260mm
|
L425*W630*H750
|
220V
|
300kg
|
